Acoustic Energy’s bespoke 1″ soft dome tweeter was designed in tandem with the 100 Series 2 bass driver to offer optimum integration and tonal matching. Paired with our Wide Dispersion Technology waveguide, the crossover region between drive units is audibly seamless whilst the high-power neodymium motor assembly ensures reliable, distortion-free high-volume playback.
The 5.2″ bass/mid driver used in the 100 Series 2 has been developed with a high power, long excursion motor to provide satisfying volume levels and bass extension from relatively compact enclosures. The doped paper cone enables a higher crossover point for smoother mid-range and seamless crossover with the tweeter, creating extremely high fidelity, detailed and above all musical sound reproduction.
The 100 Series 2 uses a substantial 0.6″ thick high density (HDF) enclosure with carefully tuned bracing, reducing harmful resonances while retaining body and substance from compact, practical cabinets. The rear slot porting enhances smooth bass extension with minimal room impact, allowing easy placement. The AE109² and AE120² feature inert mass-loading for additional stability and acoustic damping, all models come supplied with slim magnetic grilles.
Drive Unit: 5.2″ Doped Paper Cone
Tweeter: 1″ Soft Dome
Frequency Range: 41 Hz to 26 KHz
Sensitivity: 89 dB
Peak SPL: 115 dB
Power Handling: 175 Watts
Crossover Frequency: 275 Hz, 2.5 KHz
Impedance: 6 Ohms
Design: 2.5 – way
Grilles: Slim Magnetic Fit
Dimensions: 34″ H x 6.5″ W x 10″ D
Weight: 35 lbs each
Finishes: Satin Black and Walnut vinyl veneer
Watch Tarun, A British Audiophile, explain why he thinks the AE109 Mk2 is the best budget floor stander on he market.
